TSC TDP-247 Service Manual

12
1.4. Supply Specification
1.4.1. Paper
Item
Specification
Type
Label (Continuous , Die-cut , Fan-fold)
Wound Type
Outside wound
Width
20mm ~ 112mm (0.79” ~ 4.4”)
Length
(Peel-off and cutter mode)
10mm ~ 1000mm (0.4” ~ 39”)
25.4mm ~ 1000mm (1” ~ 39”)
Thickness
0.06mm ~ 0.19mm (max. 150g/m**2)
Roll Diameter
Max. 5”
Roll Core Diameter
25.4mm ~ 76.2mm (1” ~ 3”)
Gap Height
Min. 2 mm (min.)
Black Mark Height
Min. 2 mm (min.)
Black Mark Width
Min 8 mm (min.)

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
