TSC TDP-247 Service Manual

9
Red / Flash
This illuminates a printing error, such as head open,
paper empty, paper jam, or memory error etc.
1.3.4. Button Operation
Feed
 Press the button when the LED is green.
 It feeds the label to the beginning of the next label.
Pause
 Press the feed button during printing.
 The printing job is suspended.
Gap/Black Mark
Sensor Calibration
1.Turn off the power switch.
2. Hold on the button then turn on the power switch.
3 Release the button when LED becomes red and blinking.
(Any red will do during the 5 blinks).
 It will calibrate the gap/black mark sensor sensitivity.
 The LED color will be changed as following order：
Amber  red (5 blinks)  amber (5 blinks)  green
(5 blinks)  green/amber (5 blinks)  red/amber (5
blinks)  solid green
 It calibrates the sensor and measures the label length.
Note:
Please select gap or black mark sensor by GAP or BLINE
command prior to calibrate the sensor.
For more information about GAP and BLINE command,
please refer to TSPL2 programming manual.

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
