TSC TDP-247 Service Manual

2
1.3. Specification
1.3.1. Printer (TDP-245 Plus)
Item
Printer model
TDP-245 Plus
Resolution
203 DPI
Printing method
Direct Thermal
Print speed
2, 3, 4, 5 ips.
2, 3 ips for peel model
Max. print width
108 mm (4.25”)
Max. print length
2286mm (90”)
Enclosure
Double-walled plastic
Physical dimension
240mm (L) x 200mm (W) x 164mm (H)
Label roll capacity
5” OD
Processor
32-bit RISC high performance processor
Memory
 2MB Flash memory
 8MB DRAM
 SD card slot for memory expansion
Interface
 RS-232 (max. 115200 bps)
 Centronics
 USB 2.0 (Full speed mode)
Power
External universal switching power supply
 Input: AC 100-240V
 Output: DC 24V 3.75A
Operation switch, button
One power switch & feed button
Sensors
 Gap transmissive sensor (offset 6 mm from center)
 Black mark reflective sensor (position adjustable)
 Head open
Internal font
 8 alpha-numeric bitmap fonts
 One Monotype Imaging® CG Triumvirate Bold
Condensed scalable font

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
