TSC TDP-247 Service Manual

3
Code Page
 Codepage 437 (English - US)
 Codepage 850 (Latin 1)
 Codepage 852 (Latin 2)
 Codepage 860 (Portuguese)
 Codepage 863 (French Canadian)
 Codepage 865 (Nordic)
 Codepage 857 (Turkish)
 Codepage 861 (Iceland)
 Codepage 1250 (Latin 2)
 Codepage 1251 (Cyrillic)
 Codepage 1252 (Latin 1)
 Codepage 1253 (Greek)
 Codepage 1254 (Turkish)
 Codepage 1257 (Baltic)
 Codepage 1258 (Vietnam)
 ISO-8859-1: Latin-1 (Western European)
 ISO-8859-2: Latin-2 (Central European)
 ISO-8859-3: Latin-3 (South European)
 ISO-8859-4: Latin-4 (North European)
 ISO-8859-5: Cyrillic
 ISO-8859-7: Greek
 ISO-8859-9: Turkish
 ISO-8859-10: Nordic
 ISO-8859-15: Latin9
Bar code
1D bar code
Code 39, Code 93, Code128UCC, Code128 subset A,
B, C, Codabar, Interleave 2 of 5, EAN-8, EAN-13,
EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits
add-on, MSI, PLESSEY, POSTNET, China POST
2D bar code
PDF-417, Maxicode, DataMatrix, QR code
Font & barcode rotation
0, 90, 180,270 degrees
Command set
TSPL-EZ
Media type
Continuous, die-cut, black mark, fan-fold, notch
Media wound type
Outside wound
Media width
20~112mm (0.78" ~ 4.4")

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
