TSC TDP-247 Service Manual

8
Accessories
 Windows labeling software CD disk
 Quick start guide
 USB cable
 External universal switching power supply
 Power Cord
 Label Spindle, fixing tab x2, 1.5” core adapter x2
Reliability
 TPH: 1 million inches or 12 months, which comes
first since delivery from TSC (service part)
 Platen: 50 km (service part)
Factory option
 Real time clock
 Main board integrated with internal Ethernet
Dealer option
 Peel off module assembly.
 Guillotine cutter
Full cut:
Paper thickness: 0.06~ 0.19mm, 500,000
cuts
Partial cut:
Paper thickness: 0.06~0.12mm, 500,000
cuts
Paper thickness: 0.19mm 200,000 cuts
User option
 KP-200 Plus
 KU-007 Plus
 HCS-200 long range linear image bar code scanner
 Bluetooth module
 8.4” OD External roll mount
 3” core label spindle
1.3.3. LED
LED Color
Description
Green/ Solid
This illuminates that the power is on and the device is
ready to use.
Green/ Flash
This illuminates that the system is downloading data
from PC to memory and the printer is paused.
Amber
This illuminates that the system is clearing data from
printer.
Red / Solid
This illuminates printer head open, cutter error.

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
