TSC TDP-247 Service Manual

5
User option
 KP-200
 KU-007 plus
 External Ethernet print server
 External wireless (802.11b/g) print server
 External roll mount, media OD. 214 mm (8.4”) with 1”
or 3” core
 3” core label spindle
 Contact CCD contact scanner
 Long range linear image bar code scanner
1.3.2. Printer (TDP-247/ TDP-345)
Item
Printer model
TDP-247
TDP-345
Resolution
203 DPI
300 DPI
Printing method
Direct thermal printing
Print speed
2, 3, 4, 5, 6, 7 ips.
2, 3 ips for peeler mode
2, 3, 4, 5 ips
2 ips for peeler mode
Max. print width
108 mm (4.25”)
106 mm (4.17”)
Max. print length
2286 mm (90”)
1016 mm (40”)
Enclosure
Double-walled plastic
Physical dimension
240mm (L) x 200mm (W) x 164mm (H)
9.45” (L) x 7.87” (W) x 6.46” (H)
Label roll capacity
5” OD
Processor
32-bit RISC high performance processor
Memory
 4MB Flash memory
 8MB SDRAM
 SD card reader for memory expansion
Interface
 RS-232 (max. 115200 bps)
 Centronics
 USB 2.0 (Full speed mode)
Power
External universal switching power supply
 Input: AC 100-240V
 Output: DC 24V 3.75A

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
