TSC TDP-247 Service Manual

4
Media thickness
0.06~0.19 mm (2.3~7.4 mil), max. 150g/m
2
Media core diameter
25.4~76.2 mm (1”~3”)
Label length
Min. 10 mm (0.4”)
Label length (peeler mode)
25.4~152.4 mm (1”~6”)
Label length (cutter mode)
25.4~2286 mm (1”~90”)
Gap height
Min. 2 mm
Black mark height
Min. 2 mm
Black mark width
Min. 8 mm (0.31”)
Printout bias
Vertical: 1 mm max.
Horizontal: 1 mm max.
Environment condition
Operation: 5~40
o
C, 25~85% non-condensing
Storage: -40~60
o
C, 10~90% non-condensing
Safety regulation
FCC Class B, CE Class B, C-Tick Class B, UL, CUL,
TÜ V/GS, CCC
Accessories
 BarTender UltraLite CD disk
 Quick start guide
 USB port cable
 External universal switching power supply
 Power Cord
 Label Spindle, fixing tab x2, 1.5” core adapter x2
Reliability
 TPH: 1 million inches or 12 months, which comes
first since delivery from TSC (service part)
 Platen: 50 km (service part)
Factory option
 Real time clock
 Main board integrated with internal Ethernet
Dealer option
 Peel off module assembly
 Guillotine cutter
Full cut: Paper thickness: 0.06~ 0.19mm, 500,000
cuts
Partial cut: Paper thickness: 0.06~0.12mm, 500,000
cuts
Paper thickness: 0.19mm 200,000 cuts
 Internal Ethernet print server module

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
