TSC TDP-247 Service Manual

10
Gap/Black Mark
Sensor Calibratio,
Label Length
Measurement,
Self Test and enter
Dump Mode
1.Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED becomes amber and blinking.
(Any amber will do during the 5 blinks).
 The LED color will be changed as following order.
Amber  red (5 blinks)  amber (5 blinks)  green
(5 blinks)  green/amber (5 blinks)  red/amber (5
blinks)  solid green
 It calibrates the sensor and measures the label length
and prints internal settings then enter the dump mode.
Note:
Please select gap or black mark sensor by GAP or BLINE
command prior to calibrate the sensor.
For more information about GAP and BLINE command,
please refer to TSPL2 programming manual.
Printer
Initialization
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns green after 5 amber
blinks. (Any green will do during the 5 blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks)  green
(5 blinks)  green/amber (5 blinks)  red/amber (5
blinks)  solid green
 Always do gap/black mark sensor calibration after
printer initialization.
Force Black Mark
Sensor Calibration
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns green/amber after 5
green blinks. (Any green/amber will do during the 5 blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks)  green (5
blinks)  green/amber (5 blinks)  red/amber (5
blinks)  solid green

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
