Self-test

Printer will print the printer configuration after gap/black mark sensor calibration.

Self-test printout can be used to check if there is any dot damage on the heater

element, printer configurations and available memory space.

Self-test printout

Print head check pattern

Model name and F/W version

Printed mileage (meter)

Firmware checksum

Serial port configuration

Code page

Country code

Print speed (inch/sec)

Print darkness

Label size (inch)

Gap distance (inch)

Gap/black mark sensor sensitivity

Numbers of download files

Total & available memory space

Note:

1. The physical flash memory for RoHS compliant version is 2MB Flash and

8MB SDRAM

2. System occupies 960 KB in Flash memory so total flash memory space for

user downloading is 1088 KB

3. System occupies 7936 KB in SDRAM so total SDRAM memory space for user

downloading is 256 KB
