turbofan 30D Series Service Manual

13
Parts Replacement 5
Amendment 10
11 May 2015
5.1.3 Overtemp Thermostat /
Temperature Probe
1. Remove RH louvered side panel.
2. Inside oven remove side oven rack
.
Overtemp Th
ermostat
1.
From inside the oven, remove overtemp phial ho
lder (two
screw
s
).
2.
Withdraw phial through oven cavity
.
3.
Remove wires from overtemp thermostat, noting positions.
4.
Remove mounting nut securing overtemp to mounting bracke
t
and remove th
e overtemp.
5. When replacing the overtemp use RTV silicone sealant to seal
the hole in the oven liner.
6. Refit overtemp in reverse order.
Overtemp Phial Holder
Securing Screws
Seal hole with
RTV Silicone
Temperature
Probe
Temperature Probe
Securing Screws
Mounting Nut
Temperature
Probe
1. Remove
control panel.
2. Dis
connect temperature probe cable from controller.
3. From inside oven, remove RH side oven rack.
4. Undo temperature probe securing screw(s).
5. Withdraw probe and cable through oven cavity
.
6.
Clean off any existing silicone from around the te
mperature
p
robe opening in the oven inner wall.
7. Fit the new gasket to the rear of the new temperature prob
e
and f
eed the probe cable through oven cavity
.
8.
Connect temperature probe cable to oven controller
.
9.
Secure temperature probe to oven using the supplied screws
.
1
0. Refit the control panel.
11.
Carry out a functional check of temperature probe using th
e
oven con
troller.
Temperature Probe Type PT1000
Temperature
o
C (
o
F) Resistance ± 5%
0 (30) 1000 Ω
50 (122) 1194 Ω
100 (212) 1385 Ω
150 (302) 1573 Ω
180 (356) 1685 Ω
