24
6 Controller Programming
Amendment 10
11 May 2015
6.3 Viewing / Changing Service Parameters (from Ser. No. 762120)
NOTE
: All units produced after this point are G32r03 Units, but older units can fit the new controller as a spares item, in which
case Parameter Number ‘P02’ is set to ’G32r01’.
Parameter
Number
Description Min Max
Default
U o M
Pass
0
G32R01 G32R03
P01
Temperature Scale.
Defines temperature scale used
(C = °C, F = °F). Changing scale from °F to °C will reset all
temperature parameters to their default values.
˚C ˚F ˚C
--- S
P02
Oven Model and Software Revision.
E31 r01 G32 r03
G32r01 --- S
P03
Minimum Oven Temp Set Point.
The minimum temperature
that the oven can be set to.
0 (32) 300 (572) 60 (140) ˚C (˚F) S
P04
Maximum Oven Temp Set Point.
The maximum temperature
that the oven can be set to.
0 (32) 300 (572) 260 (500) ˚C (˚F) S
P05
Minimum Core Temp Set Point.
The minimum core
temperature that can be set.
0 (32) 150 (302) N/A 50 (122) ˚C (˚F) S
P06
Maximum Core Temp Set Point.
The maximum core
temperature that can be set.
0 (32) 150 (302) N/A 90 (194) ˚C (˚F) S
PrH
Oven Default Preheat Temp.
The temperature that the oven
will pre heat to on start-up.
P3 P4 150 (300) N/A ˚C (˚F) U
P08
Hysteresis Temperature Gap.
The temperature drop from
the Set Point before the heating cycles back ‘On’.
1 (2) 10 (18) 1 (2) °C / °F S
P09
Temperature Regulation Offset.
The temperature below set
point that the oven heating turns off. i.e. If P9 is set to 5 and
oven temperature is set to 180, oven heating will turn ‘Off’ at
175. This is intended to allow for thermal over-run in the oven
cavity
.
0 (0) 10 (18)
0
°C / °F S
P10
Oven Temperature Offset.
This offset is always added to the
raw temperature measurement, to correct the value. Value
shown on display is the corrected value).
-25 (-45) 25 (45) 0 (0) 0 (0) ˚C (˚F) S
P11
Maximum Timer Set Point.
Maximum time that can be set.
1 180 180 180 min S
P12
Core Temp Verification Time.
Time required for Core Probe
to be at or above the Set Temperature before the cooking done
alarm sounds.
1 120
N/A 30
sec S
L-O
Time Light stays On.
Duration of time for which light stays
‘On’. Pressing ‘Act Temp/Light Key will turn oven light ‘On / Off’
in all settings. If 1-60min set, oven light will turn off after set
time elapsed. If ‘0’ is set, key must be pressed to turn lights ‘Off’.
0
60 0 0 min U
P13
Steam Cycle Time.
The time duration in minutes for each
steam cycle.
1 5
N/A
2 min S
P14
Steam Injection Pulse Time.
The time duration in seconds
for each steam pulse within the steam cycle (P13).
Note;- The number of steam injections per cycle is
determined by the humidity level set by the user, e.g. H1
= 1 Injection Pulse of (P14) seconds every (P13)
minutes.
0 5
N/A
1 sec S
P15
Cooling Fan Timeout.
The time that the cooling fan will
continue running after the ‘On/Off’ key has been pressed.
0 60 min S
(0) Defines the password level of the parameter (S = Service / Factory. Password level 321)
(U =
User. Password level 123)
.
10
G32r03
˚C
60 (140)
1 (2)
0
10
InJ
Steam Injection Time (sec).
0 10 0 N/A sec U
260 (500)
To Next Page
