turbofan 30D Series Service Manual

15
Parts Replacement 5
Amendment 10
11 May 2015
5.1.5 Oven Fan / Fan Motor
1. Remove RH louvered side panel.
Oven Fan
1.
Inside oven remove RH Side oven rack
.
2.
Remove the 2.5mm grub screw securing the oven
fan to the
f
an motor shaf
t.
3.
Remove the oven fan from inside the oven.
NOTE: Ensure the E-Clip is still fitted to the motor shaft
before replacing the oven fan.
3. Refit oven fan, pushing fan back against the E-Clip
.
4
. Rotate the fan until the fan securing grub screw is located
over the flat of the motor shaft.
5. Securely tighten the grub screw onto the ‘D’ section of th
e
m
otor shaft to secure the fan to motor shaft.
2.5mm Grub Screw
E-Clip
Motor Shaft
Fan Motor
1.
Remove the oven fan as shown opposite.
2. Remove and retain the E-Clip fitted to the motor shaft.
3. Disconnect motor wires from motor connection block, no
te
wire p
osition
s.
4.
Remove Motor mounting screws and remove the motor
from
the o
v
en.
5.
Replace motor and secure with 4 screws
.
6
. Reconnect motor wires to connection block, note wi
re
po
sitions.
7.
From inside the oven refit the E-Clip into the groo
ve on the
m
otor shaf
t.
8
. Refit oven fan as shown opposite.
9. Refit RH oven side panel.
Screws
E-Clip
Motor Shaft
Remove and Retain E-Clip
Motor Shaft
Grub Screw
Note Flat on Motor Shaft
for Grub Screw location.
Fan
