5.2.4 Temperature Calibration
1. Place temperature probe in the centre of the oven.
2. Close the door and allow temperature to stabilise.
3. Enter service parameters settings menu on control panel
and
che
ck P10 Temperature Offset (refer to Sectio
n 6.
‘View
ing / Changing Service Para
meters’).
5.2.5 Spark Electrode Adjustment.
The recommended gap settings for the ignition electrodes are
given in the diagram below.
‘a’ 18.3mm (+0.5mm, -0mm).
3
/
4
” (+
1
/
64
”, -0”).
‘b’ 4.5mm (+0.5mm, -0mm).
3
/
16
” (+
1
/
64
”, -0”).
FLAME SENSER
EARTH / GROUND
SPARK
‘a’
‘b’
