turck TBEN-S Series User Manual

Parameterizing and Configuring
Configuring the devices at EtherNet/IP
118
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
n Configuration Assembly – TBEN-S2-8DXP
Byte no. Bit no.
Dec. Hex. 7 6 5 4 3 2 1 0
Device Configuration Data [}112]
0…9 0x00…
0x09
- Eth2 Port-
Setup
Eth1 Port-
Setup
Quick
Connect
Parameter data [}39]
10 0x0A - - - - - - - SRO0
…
17 0x11 - - - - - - - SRO7
18 0x12 - - - - - - - EN DO0
…
25 0x19 - - - - - - - EN DO7
26 0x1A DMOD_CNT DX0
27 0x1B - - - - - - - DIFT DX0
28 0x1C IST DX0
29 0x1D -
30 0x1E DMOD_DX1
31 0x1F - - - - - - - DIFT DX1
32 0x20 IST DX1
33 0x21 -
34…37 0x22…
0x25
Parameters DX2, assignment acc. to byte 30…33 (0x1E…0x21) for DX1
38 0x26 DMOD_PWM DX3
39 0x27 - - - - - - - DIFT DX3
40 0x28 IST DX3
41 0x29 -
42…45 0x2A…
0x2D
Parameters DX4, assignment acc. to byte 30…33 (0x1E…0x21) for DX1
46…49 0x2E…
0x31
Parameters DX5, assignment acc. to byte 30…33 (0x1E…0x21) for DX1
50…53 0x32…
0x35
Parameters DX6, assignment acc. to byte 30…33 (0x1E…0x21) for DX1
54 0x36 DMOD_PWM DX7
55 0x37 - - - - - - - DIFT DX7
56 0x38 IST DX7
57 0x39 -
58 0x3A - - - - - - VAUX1 pin1 C0 (Ch0/1)
59 0x3B - - - - - - VAUX1 pin1 C1 (Ch2/3)
60 0x3C - - - - - - VAUX1 pin1 C2 (Ch4/5)
61 0x3D - - - - - - VAUX1 pin1 C3 (Ch6/7)
