V04.00 | 2021/05
119
n Configuration Assembly – TBEN-S2-4AI
Byte no. Bit no.
Dec. Hex. 7 6 5 4 3 2 1 0
Device Configuration Data [}112]
0…9 0x00…
0x09
- Eth2 Port-
Setup
Eth1 Port-
Setup
Quick
Connect
Parameter data [}39]
Channel 0
10 0x0A - - - - Operation mode
11 0x0B - - - - Thermocouple type
12 0x0C - - - - Thermocouple cold junction compensation
13 0x0D - - - - Voltage range
14 0x0E - - - - - - Voltage
wiring type
15 0x0F - - - - - - Current range
16 0x10 - - - - - - Current wiring type
17 0x11 - - - - - - Resistance range
18 0x12 - - - - - - Resistance
wiring type
19 0x13 RTD type
20 0x14 - - - - - - RTD wiring type
21 0x15 - - - - - - Data representation
22 0x16 - - - - - - - Temp.
unit
23 0x17 - - - - Input averaging filter DIFT
24 0x18 - - - - - - - Deactiv.
ch.
25 0x19 - - - - - - - Deactivate
diagn.
26 0x1A - - - - - - - Mains sup-
pression
27 0x1B -
Channel 1
28…45 0x1C…
0x2D
Assignment similar to channel 0 (byte 10…27)
Channel 2
46…63 0x2E…
0x3F
Assignment similar to channel 0 (byte 10…27)
Channel 3
64…81 0x40…
0x51
Assignment similar to channel 0 (byte 10…27)
82…83 0x52…
0x53
reserved
