Miscellaneous Parameters Class (VSC 126)
This class contains 2 instances
n Instance 1: Ethernet port ETH1
n Instance 2: Ethernet port ETH2
Attribute no. Designation Get/set Type Meaning
Dec. Hex.
109 0x6D Ethernet port paramet-
ers
G/S DWORD 0: Autonegotiate, AutoMDIX
1: 10BaseT, half duplex, linear
topology (AutoMDIX disabled)
2: 10BaseT, full duplex, linear to-
pology (AutoMDIX disabled)
3: 100BaseT, half duplex, linear
topology (AutoMDIX disabled)
4: 100BaseT, full duplex, linear
topology (AutoMDIX disabled)
112 0x73 I/O controller software
revision
G DWORD Only valid for instance 1:
Firmware version of the device
Analog Input Class (VSC 131)
One instance is assigned to each channel:
n Instance 1: Channel 0
n Instance 2: Channel 1
n Instance 3: Channel 2
n Instance 4: Channel 3
Attribute no. Designation Get/Set Type Meaning
Dec. Hex.
1 0x01 Operation mode G/S USINT 0: Thermocouple
1: voltage
2: Current
3: Resistance
4: RTD
2 0x02 Thermocouple
type
G/S USINT 0: Type K, -270…1370 °C, -454…2498 °F
1: Type B, 100…1820 °C, 212…3308 °F
2: Type E, -270…1000 °C, -454…1832 °F
3: Type J, -210…1200 °C, -346…2192 °F
4: Type N, -270…1300 °C, -454…2372 °F
5: Type R, -50…1768 °C, -58…3214 °F
6: Type S, -50…1768 °C, -58…3214 °F
7: Type T, -270…400 °C, -454…752 °F
8: Type C, 0…2315 °C, 32…4199 °F
9: Type G, 0…2315 °C, 32…4199 °F
