turck TBEN-S Series User Manual

Parameterizing and Configuring
Configuring the devices at EtherNet/IP
144
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Attribute no. Designation Get/Set Type Meaning
Dec. Hex.
4 0x04 Voltage
range
G/S USINT 0: -10…10 V
1: 0…10 V
2: 2…10 V
3: 0…5 V
4: 1…5 V
5: -1…1 V
6:-500…500 mV
7: -100…100 mV
8: -50…50 mV
5 0x05 Voltage
wiring type
G/S USINT 0 = differential
1 = single ended
2 = differential without ground
6 0x06 Current range G/S USINT 0: 0…20 mA
1: 4…20 mA
2: -20…20 mA
7 0x07 Current wiring
type
G/S USINT 0 = differential
1 = single ended
2 = differential without ground
8 0x08 Resistance
range
G/S USINT 0: 0…100 Ohm
1: 0…400 Ohm
2: 0…2000 Ohm
3: 0…4000 Ohm
9 0x09 Resistance
wiring type
G/S USINT 0: 2-wire
1: 3-wire
2: 4-wire
10 0x0A RTD type G/S USINT 0: Pt100, -200…850 °C, -328…1562 °F
1: Pt100, -200…150 °C, -328…302 °F
2: Ni100, -60…250 °C, -76…482 °F
3: Ni100, -60…150 °C, -76…302 °F
4: Pt200, -200…850 °C, -328…1562 °F
5: Pt200, -200…150 °C, -328…302 °F
6: Pt500, -200…850 °C, -328…1562 °F
7: Pt500, -200…150 °C, -328…302 °F
8: Pt1000, -200…850 °C, -328…1562 °F
9: Pt1000, -200…150 °C, -328…302 °F
10: Ni1000, -60…250 °C, -76…482 °F
11: Ni1000, -60…150 °C, -76…302 °F
11 0x0B RTD
wiring type
G/S USINT 0: 2-wire
1: 3-wire
2: 4-wire
