4. REQUIRED LIGHTS AND INSTALLATION
• Chassis-cabs manufactured by Nissan Diesel Motor Co., Ltd. are
equipped with the lights shown in Table II, some of which are tempo-
rarily installed. These lights conform to FMVSS 108 and must not be
modified, changed or altered (except for relocating the temporarily in-
stalled lights).
• It is the responsibility of subsequent stage manufacturers to assure
that the lights shown in Table III are installed on the completed vehicle
in conformity with FMVSS 108.
TABLE II
*No. of: The number of lights or reflectors
FR. and RR. stand for FRONT and REAR respectively.
TABLE III
*No. of: The number of lights or reflectors
(1) lnstallation of Lights not Supplied with the lncomplete Vehicle
(a) Power
The power outlet for the rear body lights is located in front of the third
crossmember of the left-hand side rail. The maximum power supplied
from this outlet is 108 watts (12 volts at 9 amp.).
Follow the instructions provided in paragraph 5 if the total power re-
quirement exceeds 108 watts. When installing circuitry for the rear
body lights, use an SAE Type 1A 1/4 terminal (see SAE J858a) and
an automotive low-tension wire AWG 16,(1.25 mm
2
). Connect the ter-
minal securely and insulate it so that it is water-tight.
(b) Light locations
Added lights must be installed to assure vehicle compliance with the
requirements of FMVSS 108. If any light is hidden by the body or
other structure after the vehicle is completed, a component(s)
conforming to FMVSS 108 must be installed. Refer to FMVSS 108
for installation location.
Description *No. of Color Remarks
Headlights 2 White
FR. turn signal lights 2 Amber
FR. side turn signal lights 2 Amber
FR. side reflex reflectors 2 Amber
FR. identification light 3 Amber
FR. clearance light 2 Amber
RR. combination 2 --- Temporarily installed to rear of frame
• Tail 2 Red
• Stop 2 Red
• Rear turn 2 Amber
• Rear reflex reflectors 2 Red
License plate light 1 White Temporarily installed to rear of frame
Back-up lights 2 White
Description *No. of Color Remarks Maximum power
supplied
Front clearance light 2 Amber Total 108W
Rear clearance light 2 Red (12V at 9A)
Rear identification light 3 Red
Rear side maker light 2 Red
Intermediate side reflex
reflector
2 Amber
Intermediate side
marker light
2 Amber Vehicle whose over-
all length is over 30
ft. only
Room light (Rear body) - White Total 48W
(12V at 4A)
C21
