UD Trucks UD2000 - Propeller Shaft Data

PROPELLER SHAFT DATA
Unit : inch (mm)
OD : Outside Diameter “* L
1
” IS CONSTANT VALUE.
ID : Inside Diameter
T : Thicness
T/M
TYPE
P/S
MODEL
INSTALLING
LENGTH
P/S DIMENSION
OD X ID X T
PERMISSIBLE LENGTH
L
1
L
2
*L
1
L
2
MAX L
2
MIN
UD1400A ATM PS860 —
38.27
(972)
3.54 X 3.29 X 0.13
(90 X 83.6 X 3.2)
—
39.13
(994)
37.72
(958)
UD1400C ATM PS860
23.54
(598)
37.48
(952)
3.54 X 3.29 X 0.13
(90 X 83.6X 3.2)
23.54
(598)
38.35
(974)
36.93
(938)
UD1400E ATM PS860
41.26
(1,048)
37.24
(946)
3.54 X 3.29 X 0.13
(90 X 83.6 X 3.2)
41.26
(1,048)
38.35
(974)
36.93
(938)
B28
NOTE:
THE PROPELLER SHAFT SHOULD NOT BE SHORTENED
TO A LENGTH SHORTER THAN THE SHORTEST OFFER-
ED BY NISSAN DIESEL MOTOR CO., LTD. IN THE SAME
MODEL.
LIKEWISE, THE PROPELLER SHAFT SHOULD NOT BE
LENGTHENED TO A LENGTH LONGER THAN THE
LONGEST OFFERED BY NISSAN DIESEL MOTOR CO.,
LTD. IN THE SAME MODEL.
IN CASE OF PROPELLER SHAFT MODIFICATION, THE
PROPELLER SHAFT LAYOUT SHOULD CORRESPOND
WITH A WHEELBASE OFFERED BY NISSAN DIESEL
MOTOR CO., LTD.
