4. REQUIRED LIGHTS AND INSTALLATION
• Chassis-cabs manufactured by Nissan Diesel Motor Co., Ltd. are
equipped with the lights shown in Table II, some of which are
temporarily installed. These lights conform to FMVSS 108 and must
not be modified, changed or altered (except for relocating the
temporarily installed lights).
• It is the responsibility of subsequent stage manufacturers to assure
that the lights shown in Table III are installed on the completed vehicle
in conformity with FMVSS 108.
TABLE II
*No. of : The number of lights or reflectors
FR. and RR. stand for FRONT and REAR respectively.
TABLE III
*No. of : The number of lights or reflectors
(1) Installation of Lights not supplied with the incomplete vehicle
(a) Power
The power outlet for the rear body lights is located in front of the
third crossmember of the left-hand side rail. The maximum power
supplied from this outlet is 108 watts (12 volts at 9 amp.).
Follow the instructions provided in paragraph 5 if the total power
requirement exceeds 108 watts. When installing circuitry for the
rear body lights, use an SAE Type 1A 1/4 terminal (see SAE J858a),
and an automotive low-tension wire AWG 16, (1.25 mm
2
). Connect
the terminal securely and insulate it so that it is water-tight.
Description *No. of Color Remarks
Headlights 2 White
FR. turn signal lights 2 Amber
FR. side reflex reflectors 2 Amber
FR. identification light 3 Amber
FR. clearance light 2 Amber
RR. combination 2 --- Temporarily installed to rear of frame
• Tail 2 Red
• Stop 2 Red
• Rear turn 2 Amber
• Rear reflex reflectors 2 Red
License plate light 1 White Temporarily installed to rear of frame
Back-up lights 2 White
Description *No. of Color Remarks
Maximum power
supplied
Front clearance light 2 Amber Total 108W
Rear clearance light 2 Red (12V at 9A)
Rear identification light 3 Red
Rear side maker light 2 Red
Intermediate side reflex
reflector
2 Amber
Intermediate side
marker light
2 Amber Vehicle whose over-
all length is over 30
ft. only
C19
