Ulma ENKOFORM VMK - Column Solution

ENKOFORM VMK
Construcción
46


ENKOFORM VMK
4.11. COLUMN SOLUTION
ENKOFORM VMK also allows solving formwork
columns.
General view of the formwork column.
The column formwork consists of two column
PANELS joined to each other by means of the
OUTSIDE CORNER HEAD MK, WEDGES MK, TIE RODS
15 and PLATE NUTS 15.
Top view of a column by means of the formwork ENKOFORM
VMK.
On the other hand, column PANELS are formed by
MK-120 WALERS, VM 20 BEAMS, RVM20 CLAMPS, E
V-100 LIFTING BRACKETS, CORNER CONNECTORS,
BOARDS and planks.
The 2 COLUMN PANELS that form the column formwork.
Tie rod 15
Outside corner head MK
Plate
nut 15
Corner connector MK
Outside corner head MK
Waler MK-120
Beam VM20
