ENKOFORM VMK
5. FEATURES
5.1. FEATURES OF THE MAIN COMPONENTS
5.1.1 WALER MK-120
The properties of the WALER MK-120 are:

m = 27,5 kg/m mass/m
A = 27 10
-4
m
2
area of the net section
Av
zz
=12,32 10
-4
m
2
shear area
I
yy
= 678 10
-8
m
4
moment of inertia
W
elyy
= 113 10
-6
m
3
section modulus
f
y
= 275 MPa Yield strength
Technical features of MK-120 WALERS are (for working loads in SLS):
V
Rdzz
= 118,5 kN (Considering that N and M are 0) Maximum shear force
M
Rdyy
= 21,3 [kN m] (Considering that N and V are 0) Maximum bending moment in axis y-y
z
z
y
y
