ENKOFORM VMK
4.5.2 By means of the compensation plate
Components used to connect two PANELS with a
COMPENSATION PLATE between them are: ADJUS.
COMPENSATION CONNECTOR MK, ADJUS.
COMPENSATION HEAD MK, and 1” PUSH-PULL PROP.
They are connected by means of the PIN E20x70.
Connection between two PANELS by means of a COMPENSATION
PLATE between them.
The COMPENSATION PLATE is usually used for the
stripping (once the wall has been concreted), when it
is a non-fair-faced wall.
The main functions of the ADJUS. COMPENSATION
CONNECTOR MK with the ADJUS. COMPENSATION
HEAD MK and the PUSH-PULL PROPS are:
 To connect 2 PANELS with a gap between them.
 To correct possible errors that may be made in
the assembly of the PANELS.
Two PANELS connected to each other with a COMPENSATION
PLATE placed between them.
