ENKOFORM VMK
MK-120 waler type
Gap between TIE RODS
15 [mm]
Maximum deflection in
span[mm]
Maximum deflection in
cantilever. [mm]
Max. working load in the
WALER [kN/m]
Working load in the TIE
ROD 15 [kN]
3.625
0.23 0.91 88.1 90
4.125
0.23 0.74 84.9 90
4.625
0.30 0.44 74.4 90
4.875
0.79 0.55 65.9 90
4.875
0.20 0.80 86 90
5.625
0.30 0.56 73.5 90
