ENKOFORM VMK
Construcción
7


ENKOFORM VMK
 Formwork BOARD: the type of BOARD will be
selected depending on the number of times it
will be used and the desired concrete-end
quality.
 Concrete pressure: depending on the concrete
pressure, the gap between the VM20 BEAMS
and MK-120 WALERS in the PANELS will be
bigger or smaller.
Configuration of a PANEL for a 30 kN/m2 concrete pressure.
The main advantage of this system is that PANELS
will be assembled with the required shape. This
provides the possibility of adjusting them to the
concrete pressure and the geometry of the wall.
Configuration of a PANEL for a 90 kN/m2 concrete pressure.
In contrast to modular PANELS such as ORMA,
ENKOFORM VMK PANELS of both sides do not need
to be the same. Therefore, the solutions for corners,
pilasters and closures are easier with ENKOFORM
VMK.
In ENKOFORM VMK, the system unit is the PANEL
.
