Unitronics Unistream URD-0800 - How to Remove the Adapter Module from the DIN-Rail; How to Remove the RTB (Removable Terminal Block) from the I;O Module

Unitronics
13
How to Remove the Adapter Module from the DIN-Rail
1. Pull the white locking latch. 2. Pull the module off the rail.
How to remove the RTB (Removable Terminal Block) from the I/O module
1. Pull out the plastic belt from the RTB. 2. Apply more force until the I/O module is pulled away from
the I/O module.
