Unitronics Unistream URD-0800 - URD-0004 SK (DO04 SK) - 4 Solid State Relay

Unitronics
71
URD-0004SK (DO04SK) - 4 Solid State Relay
Items
Specification
Output per module
4 Points, Bi-directional
Indicators (Logic side)
4 Green Output state
Relay Type
MOS Relay (Solid State Relay)
Output Voltage Range
( Load Dependent )
Max. 240VAC @ 0.5A resistive
Max. 240VDC @ 0.5A resistive
Output Delay Time
(resistive load)
Max. AC/DC : 240V
OFF to ON : Max. 0.6ms
ON to OFF : Max. 3ms
Output Current Rating
Max. 0.5A per channel
Frequency Range (VAC)
47Hz ~ 63Hz
Commons Type
4Points / 2COM (Single Common)
Power dissipation
80mA @ 5.0VDC
Isolation
I/O to Logic : Isolation
Field Power : Non-isolation
Field Power
Supply Voltage : 24VDC
Voltage Range : 15 ~ 32VDC
(AC Power Not Used)
Wiring
I/O Cable Max. 2.0

(AWG 14)
Weight
58g
Module Size
12mm x 99mm x 70mm
Operating temperature
-40°C to 70°C (-40°F to 158°F)
