Unitronics Unistream URD-0800 - URD-0032 CG-4 (DO32 C4) - 32 Digital Outputs, (Source)

Unitronics
53
URD-0032CG-4 (DO32C4) - 32 Digital Outputs, (Source)
Items
Specification
Outputs per module
32 Points Source type
Indicators(Logic side )
32 Green Output status
Output Voltage Range
Nominal 24VDC
Min. 15VDC to Max. 32VDC
ON-state voltage drop
Max. 0.3Vdc @ 25 ºC )77°F( / 0.5Vdc@ 60 ºC )140°F(
ON-State Min. Current
Min. 1mA / Channel
OFF-State Leakage current
Max. 5uA
Output Signal Delay
OFF to ON : 0.3ms maximum
ON to OFF : 0.3ms maximum
Output Current Rating
Max. 0.3A per channel /Max. 6.0A per unit
COMMON Type
32 points / 4 Common
Power dissipation
65mA maximum @ 5.0VDC
Isolation
I/O to Logic : Photocoupler Isolation
Field Power : Non-Isolation
Field Power
Supply voltage : 24VDC nominal
Voltage range : 15 to 32VDC
Power dissipation: 30mA @ 32VDC
Wiring
Module connector : HIF3BA-40D-2.54R
Weight
63g
Module Size
12mm x 109mm x 70mm
Operating temperature
-40°C to 70°C (-40°F to 158°F)
