Unitronics Unistream URD-0800 - URD-0004 SM (DO04 SM) - 4 Solid State Relay

4/19
Unitronics
74
URD-0004SM (DO04SM) - 4 Solid State Relay
Items
Specification
Output per module
4 Points, Bi-directional
Indicators (Logic side)
4 Green Output state
Relay Type
MOS Relay (Solid State Relay)
Output Voltage Range
( Load Dependent )
Max. 110VAC @ 1A resistive
Max. 110VDC @ 1A resistive
Output Delay Time
(resistive load)
AC:
OFF to ON : Max. 1ms
ON to OFF : Max. 3ms
DC:
OFF to ON : Max. 1.5ms
ON to OFF : Max. 3ms
Output Current Rating
Max. 1A per channel
60 ºC (140°F) : 0.8A per channel
50 ºC (122°F) : 1A per channel
Frequency Range (VAC)
47Hz ~ 63Hz
Commons Type
4Points / 2COM (Single Common)
Power dissipation
80mA @ 5.0VDC
Isolation
I/O to Logic : Isolation
Field Power : Non-isolation
Field Power
Supply Voltage : 24VDC
Voltage Range : 15 ~ 32VDC
(AC Power Not Used)
Wiring
I/O Cable Max. 2.0

(AWG 14)
Weight
58g
Module Size
12mm x 99mm x 70mm
Operating temperature
-40°C to 60°C (-40°F to 140°F)
