Unitronics Unistream URD-0800 - URD-0032 NG-4 (DO32 N4) - 32 Digital Outputs, (Sink)

Unitronics
65
URD-0032NG-4 (DO32N4) - 32 Digital Outputs, (Sink)
Items
Specification
Outputs per module
32 Points Sink Type
Indicators
32 Green Output Status LEDs
Output Voltage Range
24VDC
Min. 15VDC to Max. 32VDC
ON-state voltage drop
Max. 0.3Vdc @ 25 ºC (77°F) / 0.5Vdc @ 60 ºC (140°F)
ON-State Min. Current
Min. 1mA / Channel
OFF-State Leakage current
Max. 25uA
Output Signal Delay
OFF to ON : 0.3ms maximum
ON to OFF : 0.3ms maximum
0ch~15ch < 16ch~31ch : max. 20us
Output Current Rating
Max. 0.3A per channel / Max. 6.0A per unit
COMMON Type
32 points / 4 Common
Power dissipation
65mA maximum @ 5.0VDC
Isolation
I/O to Logic : Photocoupler Isolation
Field Power : Non-Isolation
Field Power
Supply voltage : 24VDC nominal
Voltage range : 15 to 32VDC
Power dissipation: 10mA @32.0VDC
Wiring
Module connector : HIF3BA-40D-2.54R
Weight
59g
Module Size
12mm x 109mm x 70mm
Operating temperature
-40°C to 70°C (-40°F to 158°F)
