Unitronics Unistream URD-0800 - URD-0400 C (DI04 C) - 4 Digital Inputs

Unitronics
35
URD-0400C (DI04C) - 4 Digital Inputs
Items
Specification
Inputs per module
4 Points Sink type
Indicators
4 Green input state
ON–state Voltage
240VAC nominal
Min. 170VAC to Max. 264VAC
ON-state current
7.5mA maximum/point @120VAC
Input Signal Delay
OFF to ON : 30ms @ 240VAC
ON to OFF : 140ms @ 240VAC
Nominal Input Impedance
26.5K ohm typical
COMMON Type
4 Points / 4 Common ( L2/N )
Power dissipation
30mA maximum @ 5.0VDC
Isolation
I/O to Logic : Photocoupler isolation
Field Power
Supply voltage : 24VDC
Voltage range : 15 to 32VDC
(AC Power Not used)
Wiring
I/O Cable Max. 2.0

(AWG 14)
Weight
57g
Module Size
12mm x 99mm x 70mm
Operating temperature
-40°C to 60°C (-40°F to 140°F)
