Specifications
Items
Specification
Max. Expansion Module
Up to 63 slots
The adapter is limited to process 192 data bytes for inputs and 192 data bytes for
outputs.
Each digital input/output point process data is 1 bit (minimum 1 byte per module if
module data size is less than 8 points) while each analog input/output is 2 bytes
(8 inputs/outputs module will be 16 bytes of process data).
Max Length Bus Line
Up to 100m from Ethernet Hub/Switch with twisted CAT5 UTP/STP
Max. Nodes
Limited by Ethernet Specification.
Baud Rate
10/100Mbps, Auto-negotiation, Full duplex
Interface Connector
2 ports, RJ-45 socket
IP-Address Setup
DIP Switch or DHCP/BOOTP
IP-Address Range
xxx.xxx.xxx.1 ~ 253 (User area)
xxx.xxx.xxx.254 ~ 255 (Reserved for IAP Function)
Indicator
6 LEDs
1 Green/Red, Module Status (MOD)
1 Green, Physical Connection (LINK)
1 Green, Exchange Data/Traffic Present (ACTIVE)
1 Green/Red, Expansion I/O Module Statsus (IOS)
1 Green, System Power Status
1 Green, Field Power Status
2 LEDs (each RJ45 Connector)
1 Yellow, Link/Active
1 Green, Not used
For detailed indicators description, please follow the "LED indicators" section
bellow.
System Power
Supply voltage : 24VDC nominal
Supply voltage range : 15~32Vdc
Protection :
 Output current limit (Min. 1.5A)
 Reverse polarity protection
Power Dissipation
70mA typical @ 24VDC
Current for I/O Module
1.5A @ 5VDC
Isolation
System power to internal logic : Non-isolation
System power I/O driver : Isolation
Field Power
Supply voltage : 24VDC typical (Max. 32VDC)
Field Power Range is different depending on URI module series.
Refer to URI module`s specification.
Max. Current Field Power Contact
DC 10A Max
Weight
162g
Module Size
54mm x 99mm x 70mm
