URD-0016CG-8 (DO16C8) - 16 Digital Outputs, (Source)
Items
Specification
Outputs per module
16 Points Source type
Indicators(Logic side )
8 Green Output status
Output Voltage Range
Nominal 24VDC
Min. 15VDC to Max. 32VDC
ON-state voltage drop
Max. 0.3Vdc @ 25 ºC )77°F( / 0.5Vdc@ 70 ºC )158°F(
ON-State Min. Current
1mA per output
OFF-State Leakage current
Max. 5uA
Output Signal Delay
OFF to ON : 0.3ms maximum
ON to OFF : 0.3ms maximum
Output Current Rating
Max. 0.3A per channel / Max. 4.8A per unit
COMMON Type
16 points / 2COM (Single Common)
Power dissipation
50mA maximum @ 5.0VDC
Isolation
I/O to Logic : Photocoupler isolation
Field Power
Supply voltage : 24VDC nominal
Voltage range : 15 to 32VDC
Power dissipation: 40mA @ 32VDC
Wiring
I/O Cable Max. 0.32

(AWG 22)
Weight
52g
Module Size
12mm x 99mm x 70mm
Operating temperature
-40°C to 70°C (-40°F to 158°F)
