Unitronics Unistream URD-0800 - URD-0200 E (DI02 E) - 2 High Speed Counters; Encoder Inputs

4/19
Unitronics
38
URD-0200E (DI02E) - 2 High Speed Counters / Encoder Inputs
Items
Specification
Number of Channel
2 Channels
- Encoder, High Speed Counter, Frequency measurement
Pulse width & Period measurement
Indicators
4 Green Terminal Input LEDs
Input Voltage
5 to 24VDC
Input Current
3.0mA@4.5VDC
4.0mA @ 24VDC
Min On-State Volt/Current
≥3.5VDC
Max Off-State Volt/Current
≤3.0VDC
Power dissipation
155mA maximum @ 5.0VDC
Isolation
I/O to Logic : Photocoupler isolation
I/O to Field Power : Non-Isolation
Field Power
Supply voltage : 24Vdc nominal
Voltage range : 18 to 32VDC
Wiring
I/O Cable Max. 2.0

(AWG 14)
Weight
60g
Module Size
12mm x 90.5mm x 65mm
Operating temperature
-40°C to 70°C (-40°F to 158°F)
