Unitronics Unistream URD-0800 - URD-1600-8 (DI168) - 16 Digital Inputs (Sink; Source)

4/19
Unitronics
26
URD-1600-8 (DI168) - 16 Digital Inputs (Sink / Source)
Items
Specification
Inputs per module
16 Points Universal Digital Type
Indicators
16 Green input state
ON–state Voltage
24VDC nominal
70°C (158°F) - Min. 15 VDC to Max. 28.8 VDC
60°C (140°F) - Min. 15 VDC to Max. 32 VDC
ON-state current
3.05mA maximum/input @32VDC
Input Signal Delay
OFF to ON : 0.3ms Max
ON to OFF : 0.3ms Max
Nominal Input Impedance
14.9K ohm typical
COMMON Type
16 points / 2 COM
Power dissipation
50mA maximum @ 5.0VDC
Isolation
I/O to Logic : Photocoupler Isolation
Field Power
Supply voltage : 24VDC nominal
Voltage range : 15 to 32VDC
Power dissipation : 0mA @ 32VDC
Wiring
I/O Cable Max. 

(AWG 18)
Weight
63g
Module Size
12mm x 109mm x 70mm
Operating temperature
-40°C to 70°C (-40°F to 158°F)
