URS-08TC-2 (S08TC2) - 8 Thermocouple / mV
Items
Specification
Inputs per module
8 Channels
Indicators(Logic side )
8 Green Input status , 1 Green Input CJ status
Sensor Types
Thermal Couple Input Range
Type
Maximum Input Range
Recommended Input Range
K
-270 ~ 1372°c (-454°F, 2420.6°F)
-200 ~1200°c (-328°F, 2192°F)
J
-210 ~ 1200°c (-346°F, 2192°F)
-40 ~ 1100°c (-40°F, 2012°F)
T
-270 ~ 400°c (-454°F, 752°F)
-200 ~ 350°c (-328°F, 662°F)
B
30 ~ 1820°c (86°F, 3308°F)
600 ~ 1700°c (-1112°F, 3092°F)
R
-50~1768°c (-58°F, 3214.4°F)
0 ~ 1600°c (-32°F, 2912°F)
S
-50 ~ 1768°c (-58°F, 3214.4°F)
0 ~ 1600°c (-32°F, 2912°F)
E
-270 ~ 1000°c (-454°F, 1832°F)
-200 ~ 800°c (-328°F, 1472°F)
N
-270 ~ 1300°c (-454°F, 2372°F)
-200 ~ 1250°c (-328°F, 2282°F)
L
-200 ~ 900°c (-328°F, 1652°F)
-100 ~ 850°c (-148°F, 1562°F)
U
-200 ~ 600°c (-328°F, 1112°F)
-100 ~ 550°c (-148°F, 1022°F)
C
0 ~ 2310°c (-32°F, 4190°F)
100 ~ 2100°c (212°F, 3812°F)
D
0 ~ 2490°c (-32°F, 4514°F)
100 ~ 2200°c (212°F, 3992°F)
10uV Input
-81.0 ~ 81.0mV, 10uV/ 1 Count
1uV Input
-32.7 ~ 32.7mV, 1uV/ 1 Count
2uV Input
-65.5 ~ 65.5mV, 2uV/ 1 Count
Module Accuracy
( Need 20 minute preheating
to get enhanced accuracy. )
Recommend Input Range
±0.1% Recommended Scale @ 25°C (77°F) ambient
±0.3% Recommended Scale @ 40°C to 70°C (-40°F to 158°F)
T,B,R,S,C,D type Recommend Input Range
±0.3% Recommended Scale @ 40°C to 70°C (-40°F to 158°F)
External Cold Junction(PT100)
±2%Recommended Scale @ 40°C to 70°C (-40°F to 158°F)
Connection Method
2-Wire
Conversion Time
Average Conversion time < 330 ms
Cold junction temperature
Internal
- TMP275AIDGKR : -40°C to 125°C (-40°F to 257°F)
External
- PT100 : -45°C to 95°C (-40°F to 203°F)
Data Format
16bits Integer (2' complement )
Calibration
Not Required
Power dissipation
Max. 150mA @ 5.0Vdc
Isolation
I/O to Logic : Isolation
Field power : Not Connected
Field Power
Not used, Field power bypass to next expansion module
Wiring
I/O Cable Max. 2.0

(AWG 14)
Weight
60g
Module Size
12mm x 99mm x 70mm
Operating temperature
40°C to 70°C (-40°F to 158°F)
