Unitronics Unistream URD-0800 - URD-0800 (DI08) - 8 Digital Inputs (Sink or Source)

Unitronics
23
URD-0800 (DI08) - 8 Digital Inputs (sink or source)
Items
Specification
Inputs per module
8 Points Universal type
Indicators
8 Green Input state
ON–state Voltage
24VDC nominal
Min. 15VDC to Max. 32VDC
OFF-state voltage
8.3VDC @ 25 ºC (77°F)
ON-state current
3.03mA maximum/input @32VDC
Input Signal Delay
OFF to ON : 0.3ms Max
ON to OFF : 0.3ms Max
Input filter
Adjustable, up to 10ms
Nominal Input Impedance
10.2K ohm typical
COMMON Type
8 points / External 2COM (Universal)
Power dissipation
35mA maximum @ 5.0VDC
Isolation
I/O to Logic : Optocoupler Isolation
Field Power
Supply voltage : 24VDC nominal
Voltage range : 15 to 32VDC
Power dissipation : 0mA @ 24VDC
Wiring
I/O Cable Max. 

(AWG 14)
Weight
39g
Module Size
12mm x 99mm x 70mm
Operating temperature
-40°C to 70°C (-40°F to 158°F)
