Unitronics Unistream URD-0800 - URD-0008 CH (DO08 CH) - 8 Digital Outputs (Source)

4/19
Unitronics
44
URD-0008CH (DO08CH) - 8 Digital Outputs (Source)
Items
Specification
Outputs per module
8 Points, Sink type
Indicators(Logic side )
8 Green Output status
Output Voltage Range
Nominal 24VDC
Min. 15VDC to Max. 32VDC
ON-state voltage drop
Max. 0.5VDC @ 25 ºC, 70 ºC (158°F), -40 ºC (-40°F)
Field Power OFF-state voltage
4.6Vdc @ 25 ºC (77°F)
ON-State Min. Current
1mA per output
OFF-State Leakage current
Max. 25uA
Output Signal Delay
OFF to ON : 0.3ms maximum
ON to OFF : 0.3ms maximum
Output Current Rating
Max. 0.5A per channel / Max. 4A per unit
Protection
Over Current limit : Min 6.5A@ 25 ºC (77°F) per each outputs
Thermal Shutdown : Min 4A@ 25 ºC (77°F) per each outputs
Short circuit protection
COMMON Type
8 points / Internal 2Com
Power dissipation
40mA maximum @ 5.0VDC
Isolation
I/O to Logic : Isolation
Field Power : Non-isolation
Field Power
Supply voltage : 24VDC nominal
Voltage range : 15 to 32VDC
Power dissipation: 10mA @ 24VDC
Wiring
I/O Cable Max. 2.0

(AWG 14)
Weight
40g
Module Size
12mm x 99mm x 70mm
Operating temperature
-40°C to 70°C (-40°F to 158°F)
