URD-3200-4 (DI324) - 32 Digital Inputs (Sink / Source)
Items
Specification
Inputs per module
32 Points Universal Digital Type
Indicators
32 Green Input Status LEDs
ON–state Voltage
24VDC nominal
Min. 15VDC ~ Max. 32VDC
ON-state current
3mA maximum/input @32VDC
Input Signal Delay
OFF to ON : 0.2ms Max
ON to OFF : 0.2ms Max
Nominal Input Impedance
10.2K ohm typical
COMMON Type
32 Point / External 8COM(Universal)
Power dissipation
55mA maximum @ 5.0VDC
Isolation
I/O to Logic : Photocoupler Isolation
Field Power
Supply voltage : 24VDC nominal
Voltage range : 15 to 32VDC
Power dissipation : 0mA @ 24VDC
Wiring
Module connector : HIF3BA-40D-2.54R
Weight
59g
Module Size
12mm x 109mm x 70mm
Operating temperature
-40°C to 70°C (-40°F to 158°F)
