1. Wiring Diagram
Pin No.
Signal Description
Pin No.
Signal Description
0
0VDC/L2
1
0VDC/L2
2
0VDC/L2
3
0VDC/L2
4
0VDC/L2
5
0VDC/L2
6
0VDC/L2
7
0VDC/L2
8
0VDC/L2
9
0VDC/L2
