Upright SL20 Series User Manual

Page 6-39
Illustrated Parts Breakdown - Beacon Assembly
SL20
Beacon Assembly
101192-020
Item Part Description QTY.
1 063193-000 BRACKET, LIGHT MOUNT 2
2 012848-004 BEACON 2
4 011249-003 NUT, #10-32 UNF LOCK 8
5 011826-008 SCREW, #10-32 UNF RD MACHINE X 1 LG 8
6 029400-099 WIRE, 16 AWG, COPPER RED 12 FT
8 029931-003 CONNECTORS, PUSH TERMINAL 4
9 029620-002 CONNECTOR, BUTT 16-14 GA, (BLUE) 4
10 029452-099 WIRE, 16 AWG COPPER BLACK 12 FT
11 029620-003 CONNECTOR, BUTT 12-10 GA, (YELLOW) 1
12 029610-006 CONNECTOR, FORK #6 16-14 1
13 029601-013 CONNECTOR, RING #10 16-14 1
14 029825-002 DIODE 5 AMP 2
15 014914-001 CONNECTOR, MALE PUSH 4
