Page 6-14
Illustrated Parts Breakdown - Power Module Assembly
SL20
PowerModuleAssembly
101003-001
Item Part Description QTY.
1 101215-000 POWER MODULE TRAY WELDMENT 1
2 101141-000 MODULE COVER WELDMENT 1
3 101143-000 POWER MODULE TOP 1
4 015796-000 BATTERY 4
015798-001 BATTERY, DRY
5 063948-011 CHARGER 1
6 005299-000 LATCH, TOGGLE 2
7 025427-002 HANDLE 1
8 011252-006 SCREW, 1/4-20 UNC HEX HD CAP 3/4 2
9 011248-004 LOCKNUT, 1/4-20 UNC HEX 6
10 011829-006 BOLT, 1/4-20 UNC CARRIAGE X 3/4 1
11 011240-004 WASHER, 1/4 DIA STD FLAT 2
12 026553-004 RIVET, 1/8 1/4-3/8 GRIP 4
13 011708-004 SCREW, #8-32 UNC RD HD MACH X 1/2 8
14 011248-002 LOCK NUT #8-32 UNC HEX 8
15 011238-004 LOCKWASHER, 1/4 DIA SPLIT 4
16 011252-010 SCREW, 1/4-20 UNC HEX HD CAP 1 1/4 4
17 064466-015 CABLE ASSEMBLY 1
18 101214-000 HOLD DOWN, BATTERY 1
19 063082-000 J-BOLT 2
20 064464-000 CABLE RETAINER 1
21 063386-000 CHARGER SPACER 1
