Page 6-10
Illustrated Parts Breakdown - Linkage Assembly
SL20
Linkage Assembly
101004-020
Item Part Description QTY.
1 101036-000 PIN 1
2 101037-000 PIN 2
3 101039-000 PIN 1
4 101040-000 PIN 2
5 101030-000 LOWER BOOM WELDMENT L.H. 1
6 101023-000 ADJUSTABLE COMPRESSION TUBE WELDMENT 2
7 101035-001 LOWER TENSION LINK WELDMENT L.H. 1
8 101031-001 LOWER BOOM WELDMENT R.H. 1
9 101016-001 BUSHING- 3” LG 7
10 101059-000 UPPER BOOM WELDMENT 1
11 101048-000 RISER WELDMENT 1
12 101053-000 TENSION LINK WELDMENT 1
13 101013-000 LIFT CYLINDER 1
010013-010 SEAL KIT 1
14 101016-000 BUSHING- 2” LG 12
15 065214-000 ROD END 7
16 011254-012 SCREW, 3/8-16 UNC HEX HD CAP X 1 1/2 10
17 011248-006 LOCKNUT, 3/8-16 UNC HEX 7
18 011248-008 LOCKNUT, 1/2-13 UNC HEX 2
19 011256-018 SCREW, 1/2-13 UNC HEX HD CAP X 2 1/4 2
20 011254-014 SCREW, 3/8-16 UNC X 1 3/4 1
21 011941-005 FITTING, STRAIGHT 2
22 101204-000 PIN 1
23 101035-000 LOWER TENSION LINK WELDMENT R.H. 1
24 013987-010 SPRING 1
25 015919-000 ORIFICE (Ø .0465) 1
26 066179-000 VALVE, LOWERING 20 VDC 1
27 061692-099 EDGE TRIM 3/16 1
28 067805-099 EDGE TRIM 1/4-1/2 FT .90
29 101174-001 LADDER WELDMENT 1
30 011240-006 WASHER 3/8 FLAT 4
