Page 6-27
Illustrated Parts Breakdown - Hydraulic Tank Assembly
SL20
Hydraulic Tank Assembly
101152-000
Item Part Description QTY.
1 101056-000 TANK, HYDRAULIC 1
2 021305-006 PLUG, MAGNETIC 1
3 061818-000 STRAINER, SUCTION 1
4 011940-006 FITTING, ELBOW 1
5 011917-012 FITTING, ELBOW 1
6 011923-012 FITTING, REDUCER 1
7 012467-004 NIPPLE 3/4 NPT X 2 LG. 1
8 068982-001 CAP, HYDRAULIC FLUID 1
