Page 6-16
Illustrated Parts Breakdown - Control Valve Assembly
SL20
Control Valve Assembly
101120-121
Item Part Description QTY.
1 100020-040 CONTROL VALVE BLOCK 1
2 012004-002 FITTING #2 PLUG 9
3 012004-004 FITTING #4 PLUG 14
4 011941-005 FITTING STRAIGHT 6MB - 6MJ 3
5 011941-001 FITTING STR 4MBH - 4MJ 5
6 012004-006 FITTING PLUG #6 7
7 060390-009 RELIEF VALVA, LIFT (2000 PSI)
8 011941-010 FITTING 8MB-8MJX 1
9 060390-018 RELIEF VALVE, STEERING (1500 PSI) 1
10 060390-023 RELIEF VALVE, MAIN (3000 PSI) 1
11 063923-006 2 POS - 4 WAY SOLENOID W/ COIL (LIFT) 1
12 COIL REF
13 064845-000 3 POS - 4 WAY SOLENOID W/ COILS (STEERING) 1
14 101120-034 COUNTERBALANCE VALVE 2
16 020021-008 FITTING PLUG #8 1
17 064843-000 FLOW DIVIDER VALVE (1.0 GPM) 1
18 063973-001
2 POS POPPET VALVE W/ COIL (DEPRESSION
MECHANISM)
1
19 COIL REF
21 063965-001 FITTING GAGE 2
22 064841-000 CHECK VALVE 1
23 063923-021 3 POS - 4 WAY SOLENOID W/ COILS (DRIVE) 1
24 063977-001 PLUG 9MM 6
To Next Page
