Page 1-1SL20
Section 1
I
NTRODUCTION
1.1 P
URPOSE
This manual provides illustrations and instructions for the operation and maintenance of the
SL20 Series Work Platforms manufactured by UpRight, Inc. Selma, California.
S
COPE
This manual includes both operation and maintenance responsibilities concerning the SL20
Series Work Platform’s readiness. The Maintenance Section covers scheduled maintenance,
troubleshooting, repair, adjustment and replacement.
1.2 G
ENERAL
D
ESCRIPTION
Figure 1-1:
SL 20 Work
Platform
The SL20 Series
Work Platform is a
self-propelled aerial
work platform
designed to be used
as a means of elevat-
ing personnel and
equipment and to
provide a mobile
work platform. It is
designed to provide
mobility with the plat-
forminaraisedor
lowered position.
Travel with the plat-
form elevated is auto-
matically limited to
creep speed range.
P
URPOSE
A
ND
L
IMITATIONS
The objective of the
SL20 Series Work
Platforms is to provide a quickly deployable, self-propelled, variable height work platform. The
elevating function shall only be used when the work platform is on a firm level work area. The
work platform is intended to be self-propelled when in relatively close proximity to the work area.
1
2
3
5
4
6
1. Platform, Guard Rails
2. Elevating Assembly
3. Chassis
4. Control Module
5. Power Module
6. Joystick Controls
