Upright SL20 Series User Manual

Page 3-2
Maintenance - 3.3 - Special Tools
SL20
3.3 S
PECIAL
T
OOLS
The following is a list of special tools which may be required to perform certain maintenance pro-
cedures on the work platform.
• 0-69 bar (0-1000 psi)(0-69 bar)Hydraulic Pressure Gauge with Adapter Fittings
• 0-207 bar (0-3000 psi)(0-207 bar)Hydraulic Pressure Gauge with Adapter Fittings
• 0-414 bar (0-6000 psi)(0-414 bar)Hydraulic Pressure Gauge with Adapter Fittings
• Small Deutsch Connector Field Kit
(UpRight P/N 030899-000)
• Large Deutsch Connector Field Kit
(UpRight P/N 030898-000)
•Inclinometer
3.4 D
EUTSCH
C
ONNECTORS
Deutsch connectors are designed so that connector parts, contacts, or electrical cables may be
replaced without replacing the entire connector.
Figure 3-1:
Deutsch Connector Kit
Figure 3-2:
Plugs and Receptacles, Deutsch Connectors
Small Kit
Large Kit
