Upright SL20 Series User Manual

Page 6-37
Illustrated Parts Breakdown - Air To Platform Option
SL20
Air To Platform Option
101197-020
Item Part Description QTY.
1 063191-000 BRACKET WELDMENT 2
2 012728-000 COUPLING 1
3 012729-003 COUPLING 1
4 065610-021 CONTROLLER ASSEMBLY REF
5 101005-020 CONTROL MODULE ASSEMBLY REF
6 064274-002 HOSE FITTING 2
7 011917-007 FITTING, ELBOW 1
8 011249-003 LOCKNUT, #10-32 UNF HEX 4
9 011826-008 SCREW, #10-32 UNF RND HD MACH X 1 4
10 015770-099 HOSE, 3/8 AIR 50 FT
