7-28
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
HYDRAULIC CIRCUIT ASSEMBLY
ITEM PART-NUMBER DESCRIPTION QTY.
1 15797-000 HYDRAULIC PUMP/ ELECTRIC MOTOR UNIT 1
2 57100-000 PUMP SUCTION PORT ADAPTOR 1
3 57101-000 PUMP PRESSURE PORT ADAPTOR 1
4 57102-000 PUMP “IDLE PORT” ADAPTOR 1
5 57103-300 HYDRAULIC MOTOR ASSEMBLY 1
6 57104-300 HYDRAULIC CYLINDER ASSEMBLY C/W LET-DOWN VALVE 2
7 57105-300 MANIFOLD BLOCK ASSEMBLY 1
8 57106-000 TEST POINT FITTING 1
9 57107-300 RETURN LINE FILTER 1
10 57108-300 MAGNETIC DRAIN PLUG 1
11 57109-300 FILLER BREATHER CAP 1
12 57110-300 HOSE ASSEMBLY - TANK TO PUMP 1
13 57111-300 HOSE ASSEMBLY - PUMP TO MANIFOLD ‘P’ 1
14 57112-300 HOSE ASSEMBLY - PUMP IDLE PORT TO TANK 1
15 57113-300 HOSE ASSEMBLY - FILTER TO TANK 1
16 57114-300 HOSE ASSEMBLY- MANIFOLD TO FILTER 1
17 57115-300 HOSE ASSEMBLY - MANIFOLD TO SLEW MOTOR 1
18 57116-300 HOSE ASSEMBLY - MANIFOLD TO SLEW MOTOR 1
19 57117-300 HOSE ASSEMBLY - MANIFOLD TO LOWER CYLINDER 1
20 57118-300 HOSE ASSEMBLY - MANIFOLD TO LOWER CYLINDER 1
21 57119-300 HOSE ASSEMBLY - MANIFOLD TO UPPER CYLINDER 1
22 57120-300 HOSE ASSEMBLY - MANIFOLD TO UPPER CYLINDER 1
23 57121-000 M/M ADAPTOR - 1/4” BSP - 3/8” BSP 4
24 57122-000 M/M ADAPTOR - 3/8” BSP - 3/8” BSP 3
25 57123-000 M/M ADAPTOR - 3/8” BSP - 1/2” BSP 2
26 57124-000 BONDED SEAL 3/4” 1
27 57125-000 BONDED SEAL 3/8” 9
28 57126-000 HYDRAULIC OIL 1
