7-34
TL33 Work Platform
Illustrated Parts Breakdown
Section
7.2
CABLES AND ELECTRICAL COMPONENTS
ITEM PART-NUMBER DESCRIPTION QTY.
1
1
57192-000
57192-001
MOTOR CONTROLLER ASSEMBLY SERIAL NUMBERS 1001 TO 1132
MOTOR CONTROLLER ASSEMBLY SERIAL NUMBERS 1133 TO CURRENT
1
1
2
57180-300 LOWER CONTROL BOX ASSEMBLY
1
3
3
57181-000
57181-001
UPPER CONTROL BOX ASSEMBLY SERIAL NUMBERS 1001 TO 1132
UPPER CONTROL BOX ASSEMBLY SERIAL NUMBERS 1001 TO 1132
1
1
4 15796-001 BATTERY 6V 220 AH 4
5 63948-011 BATTERY CHARGER 24V/220V 1
6 57182-400 OUTRIGGER LIMIT SWITCH 4
7 57183-300 SLEW CUT-OUT LIMIT SWITCH 1
8 57184-400 CABLE ASSEMBLY - BATTERY TO BATTERY 1
9 57185-400 CABLE ASSEMBLY - BATTERY TO BATTERY 2
10 57186-400 CABLE ASSEMBLY - FUSE TO D.C. MOTOR 1
11 57187-400 CABLE ASSEMBLY - BATTERY TO MOTOR CONTROL UNIT 1
12 57188-400 CABLE ASSEMBLY - D.C. MOTOR TO MOTOR CONTROL UNIT 1
13 57189-400 CABLE ASSEMBLY - BATTERY TO CHARGER 1
14
14
57190-000
57190-001
TAIL BOARD ASSEMBLY SERIAL NUMBERS 1001 TO 1410
TAIL BOARD ASSEMBLY SERIAL NUMBERS 1411 TO CURRENT
1
1
15 57191-400 CABLE ASSEMBLY - TAIL’BOARD TO TOWHITCH 1
16 57470-000 7-AMP FUSE 1
17 10154-000 BATTERY TERMINAL COVER (NOT SHOWN) 8
18 57465-400 CABLE ASSEMBLY - CHARGER TO FUSE 1
19 57335-400 7-PIN TRAILER SOCKET 1
20 57334-000 7-PIN PLUG 1
21 57485-000
LINE CONTACTOR (SERIAL NUMBERS 1133 TO CURRENT)
1
22 58912-000 TILT SENSOR (OPTION) 1
